Dell Latitude 3500 Specs, user Reviews 15 inch Intel 8th Gen

Dell Latitude 3500 is a Small frame Big results laptop This small, sleek 15-inch laptop with connectivity and management features is ideal for growing businesses.

Dell Latitude 3500 laptop

Dell Latitude 3500 laptop

Dell Latitude 3500

Dell Latitude 3500

Dell Latitude 3500 Price starts from USD $600 Approximately

System Information

Dell Latitude 3500 System information
Chipset

Integrated in the processor

DRAM bus width

64-bit

FLASH EPROM

16 MB

PCIe bus

Up to Gen3

Processor Specifications

Dell Latitude 3500 Processor specifications
Intel Celeron 4205U processor (2 MB cache, 2 core count/2 threads, 1.8 GHz) Intel UHD Graphics 620, NA
8th Gen Intel Core i3-8145U processor (4 MB cache, 2 core count/ 4 threads, 2.1 GHz upto 3.9 GHz with Turbo boost, 15 W TDP) Intel UHD Graphics 620, NA
8th Gen Intel Core i5-8265U processor (6 MB cache, 4 core count/ 8 threads, 1.6 GHz upto 3.9 GHz with Turbo boost, 15 W TDP) NA, Nvidia GeForce MX130 graphics
8th Gen Intel Core i5-8365U processor (6 MB cache, 4 core count/ 8 threads, 1.6 GHz upto 4.1 GHz with Turbo boost, 15 W TDP) Intel UHD Graphics 620, Nvidia GeForce MX130 graphics
8th Gen Intel Core i7-8565U processor (8 MB cache, 4 core count/ 8 threads, 1.8 GHz upto 4.6 GHz with Turbo boost, 15 W TDP) NA, Nvidia GeForce MX130 graphics

Operating System

Dell Latitude 3500 Operating system
Operating systems supported
  • Microsoft Windows 10 Home 64 bit
  • Microsoft Windows10 Professional 64 bit
  • Windows 10S (with UMA Only)
  • Ubuntu 18.04 LTS 64-bit

Memory (RAM)

Dell Latitude 3500 Memory specifications
Minimum memory configuration

4 GB

Maximum memory configuration

32 GB

Number of slots

2 SODIMM

Maximum memory supported per slot

16 GB

Memory options
  • 4 GB (1 x 4 GB)
  • 8 GB (2 x 4 GB)
  • 8 GB (1 x 8 GB)
  • 16 GB (2 x 8 GB)
  • 16 GB (1 x 16 GB)
  • 32 GB (2 x 16 GB)
Type

DDR4 SDRAM Non-ECC memory

Speed

2400 MHz

Storage

Storage specifications
Hard Disk Drive SATA, SATA Gen 3 (5400 RPM), Up to 1 TB
SATA Solid-State Drive (Class 20) M.2 SSD 2280, SATA Gen 3, Up tp 1 TB
PCIe NVMe Solid-State Drive (Class 35) M.2 SSD 2280, PCIe Gen 3×4 NVMe, up to 32 Gbps, Up to 1 TB
PCIe NVMe Solid-State Drive (Class 35) M.2 SSD 2230, PCIe Gen 3×4 NVMe, up to 32 Gbps, Up to 1 TB
PCIe NVMe Solid-State Drive (Class 40) M.2 SSD 2280, PCIe Gen 3×4 NVMe, up to 32 Gbps, Up to 1 TB

Dimensions and Weight

Laptop Dimensions and weight
Height

Front height – 0.71 inch (18.0 mm)

Back height – 0.71 inch (18.0 mm)

Width

14.91 inch (378.66 mm)

Depth

10.05 inch (255.35 mm)

Weight

Starting 4.37 lb (1.98 kg)

Display (Screen)

Display specifications
Type
  • 15.6 inch HD (1366 x 768) Anti-Glare Non-Touch, 220 nits, TN, eDP 1.2, 16:9, HD camera and single microphone
  • 15.6 inch FHD (1920 x 1080) Anti-Glare Non-Touch, 220 nits, TN, eDP 1.2, 16:9, HD camera and single microphone
  • 15.6 inch FHD (1920 x 1080) TrueLife with Embedded Touch, 220 nits, TN, eDP 1.2, 16:9, IR camera and dual microphone
Pixels Per Inch (PPI)

HD: 100

FHD: 142

Refresh rate

60 Hz

Horizontal viewing angle (min)

+/- 40 degrees

Vertical viewing angle (min)

+10/- 30 degrees

Video | Graphics

Video card specifications
Intel UHD Graphics 620 UMA

  • Intel Core i7-8565U CP
  • Intel Core i5-8265U CP
  • Intel Core i3-8145U CPU

, Integrated, Shared system memory

  • HDMI 1.4b port
  • VGA port
  • DisplayPort
  • 1920 x 1200 @ 60Hz
  • 1920 x 1200 @ 60Hz
  • 3840 x 2400 @ 60Hz
Nvidia GeForce MX130 equivalent, 2 GB Discrete, NA, GDDR5, 2 GB

  • HDMI 1.4b port
  • VGA port
  • DisplayPort
  • 1920 x 1200 @ 60Hz
  • 1920 x 1200 @ 60Hz
  • 3840 x 2400 @ 60Hz

Battery Specifications

Battery specifications
Type
  • 42 WHr “smart” lithium-ion 3 cell battery
  • 56 WHr “smart” lithium-ion 4 cell battery
Dimension
  • Length: 175.5 mm (6.909 inch)
  • Width: 91 mm (3.58 inch)
  • Height: 5.9 mm (0.23 inch)
  • Weight: 177.7g
  • Length: 233.17 mm (9.18 inch)
  • Width: 91 mm (3.58 inch)
  • Height: 5.9 mm (0.23 inch)
  • Weight: 236.00 g
Weight (maximum)

252 g

Voltage
  • 42 WHr – 11.4 VDC
  • 56 WHr – 15.2 VDC
Life span

300 discharge/recharge cycles

Charging time when the computer is off (approximate)

4 hours

Operating time

Varies depending on operating conditions and can significantly reduce under certain power-intensive conditions

Temperature range: Operating

0°C to 35°C (32°F to 95°F)

Temperature range: Storage

-40°C to 65°C (-40°F to 149°F)

Coin-cell battery

ML1220

Camera (Web Cam) Specifications

Camera specifications
Resolution
  • Still image: 0.92 megapixels
  • Video: 1280 x 720 at 30 fps
  • Still image: 0.92 megapixels
  • Video: 1280 x 720 at 60 fps
Diagonal viewing angle
  • Camera – 86.7 degrees

Audio Specifications

Audio
Controller

Realtek ALC3204

Speakers

Two

Interface
  • Universal audio jack
  • High quality speakers
  • Noise reducing array microphones
  • Stereo headset/mic combo
Internal speaker amplifier

2W (RMS) per channel

Ports and connectors

Ports and connectors
Memory card reader

One SD 3.0 memory card reader

USB
  • One USB Type–C 3.1 Gen 1 with Power Delivery and DisplayPort
  • One USB 3.1 Gen 1 port
  • One USB 3.1 Gen 1 with PowerShare port
  • One USB 2.0 port
Security

Noble wedge lock slot

Audio

Universal audio jack

Video

One VGA and HDMI 1.4 port

Network adapter

One RJ-45 connector

Others

Touch Fingerprint reader in Power Button (optional)

One external uSIM card tray option

Communication wireless module

Communication specifications
Network adapter

Integrated Realtek RTL8111H/100/1000 Mb/s Ethernet (RJ-45 )

keyboard

Keyboard specifications
Number of keys
  • 103 (U.S. and Canada)
  • 104 (Europe)
  • 106 (Brazil)
  • 107 (Japan)
Size
  • X= 19.00 mm key pitch
  • Y= 19.00 mm key pitch
Keyboard
  • Single pointing non-backlit keyboard.
  • Backlit keyboard (optional)
Layout

QWERTY/AZERTY/Kanji

TouchPad

Touchpad specifications
Resolution
  • Horizontal: 305
  • Vertical: 305
Dimensions
  • Width: 4.13 inch (105 mm )
  • Height: 3.15 inch (80 mm)
Multi-touch

Supports four fingers

Security

Security
Trusted Platform Module (TPM) 2.0

Integrated on the system board

Firmware TPM

Optional

Windows Hello Support

Optional

Power Adapter

Power adapter specifications
Type
  • 45 W adapter 4.5 mm barrel
  • 65 W adapter 4.5 mm barrel
  • 65 W adapter, USB Type-C
  • 90 W adapter, USB Type-C
Input Voltage

100 VAC-240 VAC

Input current (maximum)
  • 180 W – 1.7 A
  • 180 W – 2.5 A
Input frequency

50 Hz-60 Hz

Output current

180 W – 3.34 A (continuous)

Rated output voltage

19.5 VDC

Temperature range (Operating)

0º to 40º C (32º to 104º F)

Temperature range (Non-Operating)

40º to 70º C (-40º to 158º F)
