Dell Latitude 5410 – Overview

The Dell Latitude 5410 is 14 inch 5000 Series laptop powered by 8th Generation Intel Core i5-8365U Processor, AMD Radeon RX 640 2 GB GDDR5 dedicated graphics card, with the support of up to DDR4 32 GB RAM having speed of 2666 MHZ operates at 2400 MHz for and a One 2.5 inch hard drive Up to 1 TB storage. It has a WLED High Definition (HD) with Resolution 1366 x 768 display screen. The maximum weight of the laptop is 1.52 kg (3.36 lb) and its equipped with 42 Whr Coin-cell battery CR2032 in the base variant. The Dell Latitude 5410 base price is US$700 but can be customized adding more specs and features.

Latitude 5410 - Bottom View

Latitude 5410 – Bottom View

Latitude 5410 - Display View

Latitude 5410 – Display View

Latitude 5410 - Palmrest View

Latitude 5410 – Palmrest View

Latitude 5410 - Sides View

Latitude 5410 – Sides View

Dell Latitude 5410 – Specs

QuickSpecs
Brand Dell
Series Dell Latitude 5000
Model Dell Latitude 5410
Price Starting from US$700
Color Silver
Processor Generation 8th Generation Intel Core i5-8365U
Display Size 355.60 mm (14.00 in.)
Weight 1.52 kg (3.36 lb)
Battery 42 Whr
Minimum RAM 4 GB
Maximum RAM 32 GB
Release Date 06 APR 2020

Dell Latitude 5410 – Technical Specifications

Processor Specifications

Processors
8th Generation Intel Core i5-8365U
  • Processors: 8th Generation Intel Core i5-8365U
  • Wattage: 15 W
  • Core count: 4
  • Thread count: 8
  • Speed: 1.60 GHz to 4.10 GHz (vPro)
  • Cache: 6 MB
  • Integrated graphics: Intel UHD Graphics 620
10th Generation Intel Core i3-10110U
  • Processors: 10th Generation Intel Core i3-10110U
  • Wattage: 15 W
  • Core count: 2
  • Thread count: 4
  • Speed: 2.10 GHz to 4.10 GHz (Non vPro)
  • Cache: 4 MB
  • Integrated graphics: Intel UHD Graphics
10th Generation Intel Core i5-10210U
  • Processors: 10th Generation Intel Core i5-10210U
  • Wattage: 15 W
  • Core count: 4
  • Thread count: 8
  • Speed: 1.6 GHz to 4.20 GHz (Non vPro)
  • Cache: 6 MB
  • Integrated graphics: Intel UHD Graphics
10th Generation Intel Core i5-10310U
  • Processors: 10th Generation Intel Core i5-10310U
  • Wattage: 15 W
  • Core count: 4
  • Thread count: 8
  • Speed: 1.7 GHz to 4.40 GHz (vPro)
  • Cache: 6 MB
  • Integrated graphics: Intel UHD Graphics
10th Generation Intel Core i7-10610U
  • Processors: 10th Generation Intel Core i7-10610U
  • Wattage: 15 W
  • Core count: 4
  • Thread count: 8
  • Speed: 1.8 GHz to 4.90 GHz (vPro)
  • Cache: 8 MB
  • Integrated graphics: Intel UHD Graphics
10th Generation Intel Core i7-10810U
  • Processors: 10th Generation Intel Core i7-10810U
  • Wattage: 15 W
  • Core count: 6
  • Thread count: 12
  • Speed: 1.1 GHz to 4.90 GHz (vPro)
  • Cache: 12 MB
  • Integrated graphics: Intel UHD Graphics

Operating System

Operating System
Operating System
  • Windows 10 Home (64-bit)
  • Windows 10 Professional (64-bit)
  • Ubuntu 18.04 LTS (64-bit)
  • NeoKylin 7.0 SP4 (PRTS)

Chipset

Chipset
Whiskey lake
  • Processors: Whiskey lake
  • Chipset: Intel
  • DRAM bus width: Two channels, 64 bits-bit
  • Flash EPROM
    • 32 MB for vPro configuration
    • 24 MB for Non-vPro configuration
  • PCIe bus: Up to Gen3
Comet lake
  • Processors: Comet lake
  • Chipset: Intel
  • DRAM bus width: Two channels, 64 bits-bit
  • Flash EPROM
    • 32 MB for vPro configuration
    • 24 MB for Non-vPro configuration
  • PCIe bus: Up to Gen3

Memory (RAM)

Memory specifications
Slots

Two SoDIMM

Type

DDR4

Speed
  • 2666 Mhz operates at 2400 MHz for Intel 8th Generation
  • 3200 Mhz operates at 2667 MHz for Intel 10th Generation
Maximum memory

32 GB

Minimum memory

4 GB

Configurations supported
  • 4 GB DDR4 at 2667 MHz (1 x 4 GB)
  • 8 GB DDR4 at 2667 MHz (2 x 4 GB)
  • 8 GB DDR4 at 2667 MHz (1 x 8 GB)
  • 16 GB DDR4 at 2667 MHz (2 x 8 GB)
  • 16 GB DDR4 at 2667 MHz (1 x 16 GB)
  • 32 GB DDR4 at 2667 MHz (2 x 16 GB)

Storage

Storage specifications
One 2.5 in. hard drive SATA, 5400/7200 RPM, Up to 1 TB
One M.2 2230 solid-state drive PCIe Gen 3 x4 NVMe, up to 32 Gbps, Up to 512 GB
One M.2 2280 solid-state drive PCIe Gen 3 x4 NVMe, up to 32 Gbps, Up to 1 TB

Storage

Storage
Storage
  • One M.2 2230/2280 slot for solid-state drive

Storage

Storage
Storage
  • with a M.2 drive, the M.2 drive is the primary drive

Dimensions and Weight

Dimensions and weight
Height:
Front height

20.26 mm (0.8 in.)

Rear height

21.18 mm (0.83 in.)

Width

323.05 mm (12.72 in.)

Depth

216 mm (8.50 in.)

Weight (maximum)

1.52 kg (3.36 lb)

Display (Screen)

Display specifications
High Definition (HD)
  • Type: High Definition (HD)
  • Panel technology: WLED
  • Luminance (typical): 220 nits
  • Dimensions (Active Area)::
  • Height: 173.95 mm (6.85 in.)
  • Width: 309.40 mm (12.18 in.)
  • Diagonal: 355.60 mm (14.00 in.)
  • Native Resolution: 1366 x 768
  • Megapixels: 1.05
  • Pixels per Inch (PPI): 112
  • Contrast Ratio (typ): 400:1
  • Response Time (max): 25 ms
  • Refresh Rate: 60 Hz
  • Horizontal View Angle: 40 degrees (Left/Right)
  • Vertical View Angle: 10 degrees (Up)/ 30 degrees (Down)
  • Pixel Pitch: 0.266 mm
  • Power Consumption (maximum): 2.4 W
  • Anti-glare vs glossy finish: Anti-glare
  • Touch options: No
Full High Definition (FHD)
  • Type: Full High Definition (FHD)
  • Panel technology: WLED
  • Luminance (typical): 220 nits
  • Dimensions (Active Area)::
  • Height: 173.95 mm (6.85 in.)
  • Width: 309.40 mm (12.18 in.)
  • Diagonal: 355.60 mm (14.00 in.)
  • Native Resolution: 1920 x 1080
  • Megapixels: 2
  • Pixels per Inch (PPI): 157
  • Contrast Ratio (typ): 700:1
  • Response Time (max): 35 ms
  • Refresh Rate: 60 Hz
  • Horizontal View Angle: 80 degrees (Left/Right)
  • Vertical View Angle: 80 degrees (Up/Down)
  • Pixel Pitch: 0.161 mm
  • Power Consumption (maximum): 2.8 W
  • Anti-glare vs glossy finish: Anti-glare
  • Touch options: No
Full High Definition (FHD)
  • Type: Full High Definition (FHD)
  • Panel technology: WLED
  • Luminance (typical): 220 nits
  • Dimensions (Active Area)::
  • Height: 173.95 mm (6.85 in.)
  • Width: 309.40 mm (12.18 in.)
  • Diagonal: 355.60 mm (14.00 in.)
  • Native Resolution: 1920 x 1080
  • Megapixels: 2
  • Pixels per Inch (PPI): 157
  • Contrast Ratio (typ): 700:1
  • Response Time (max): 35 ms
  • Refresh Rate: 60 Hz
  • Horizontal View Angle: 80 degrees (Left/Right)
  • Vertical View Angle: 80 degrees (Up/Down)
  • Pixel Pitch: 0.161 mm
  • Power Consumption (maximum): 3.15 W
  • Anti-glare vs glossy finish: Anti-glare
  • Touch options: Yes
Full High Definition (FHD) SLP
  • Type: Full High Definition (FHD) SLP
  • Panel technology: WLED
  • Luminance (typical): 300 nits
  • Dimensions (Active Area)::
  • Height: 173.95 mm (6.85 in.)
  • Width: 309.40 mm (12.18 in.)
  • Diagonal: 355.60 mm (14.00 in.)
  • Native Resolution: 1920 x 1080
  • Megapixels: 2
  • Pixels per Inch (PPI): 157
  • Contrast Ratio (typ): 700:1
  • Response Time (max): 35 ms
  • Refresh Rate: 60 Hz
  • Horizontal View Angle: 80 degrees (Left/Right)
  • Vertical View Angle: 80 degrees (Up/Down)
  • Pixel Pitch: 0.161 mm
  • Power Consumption (maximum): 2.2 W
  • Anti-glare vs glossy finish: Anti-glare
  • Touch options: No
Full High Definition (FHD)
  • Type: Full High Definition (FHD)
  • Panel technology: Privacy
  • Luminance (typical): 300 nits
  • Dimensions (Active Area)::
  • Height: 173.95 mm (6.85 in.)
  • Width: 309.40 mm (12.18 in.)
  • Diagonal: 355.60 mm (14.00 in.)
  • Native Resolution: 1920 x 1080
  • Megapixels: 2
  • Pixels per Inch (PPI): 157
  • Contrast Ratio (typ): 700:1
  • Response Time (max): 35 ms
  • Refresh Rate: 60 Hz
  • Horizontal View Angle: 80 degrees (Left/Right)
  • Vertical View Angle: 80 degrees (Up/Down)
  • Pixel Pitch: 0.161 mm
  • Power Consumption (maximum): 2.4 W
  • Anti-glare vs glossy finish: Anti-glare
  • Touch options: No

Video | Graphics (Discrete graphics)

Discrete graphics specifications
AMD Radeon RX 640 NA, 2 GB, GDDR5

Video | Graphics (Integrated graphics)

Integrated graphics specifications
Intel UHD Graphics
  • One HDMI 1.4b port
  • One USB 3.1 Gen2 Type-C port with DisplayPort Alt Mode/Thunderbolt 3

, Shared system memory

  • 8th Generation Intel Core i5
  • 10th Generation Intel Core i3/i5/i7

Battery Specifications

Battery specifications
42 Whr
  • Type: 42 Whr
  • Voltage: 11.40 VDC
  • Weight (maximum): 0.20 kg (0.44 lb)
  • Dimensions:
  • Height: 95.90 mm (3.78 in.)
  • Width: 181 mm (7.13 in.)
  • Depth: 7.05 mm (0.28 in.)
  • Temperature range::
  • Operating: 0°C to 50°C (32°F to 122°F)
  • Storage: -20°C to 60°C (-4°F to 140°F)
  • Operating time: Varies depending on operating conditions and can significantly reduce under certain power-intensive conditions.
  • Charging time (approximate): 4 hours (when the computer is off)
  • Life span (approximate): 300 discharge/charge cycles
  • Coin-cell battery: CR2032
  • Operating time: Varies depending on operating conditions and can significantly reduce under certain power-intensive conditions.
51 Whr
  • Type: 51 Whr
  • Voltage: 11.40 VDC
  • Weight (maximum): 0.25 kg (0.55 lb)
  • Dimensions:
  • Height: 95.90 mm (3.78 in.)
  • Width: 181 mm (7.13 in.)
  • Depth: 7.05 mm (0.28 in.)
  • Temperature range::
  • Operating: 0°C to 50°C (32°F to 122°F)
  • Storage: -20°C to 60°C (-4°F to 140°F)
  • Operating time: Varies depending on operating conditions and can significantly reduce under certain power-intensive conditions.
  • Charging time (approximate): 4 hours (when the computer is off)
  • Life span (approximate): 300 discharge/charge cycles
  • Coin-cell battery: CR2032
  • Operating time: Varies depending on operating conditions and can significantly reduce under certain power-intensive conditions.
68 Whr
  • Type: 68 Whr
  • Voltage: 7.60 VDC
  • Weight (maximum): 0.34 kg (0.75 lb)
  • Dimensions:
  • Height: 95.90 mm (3.78 in.)
  • Width: 181 mm (7.13 in.)
  • Depth: 7.05 mm (0.28 in.)
  • Temperature range::
  • Operating: 0°C to 50°C (32°F to 122°F)
  • Storage: -20°C to 60°C (-4°F to 140°F)
  • Operating time: Varies depending on operating conditions and can significantly reduce under certain power-intensive conditions.
  • Charging time (approximate): 4 hours (when the computer is off)
  • Life span (approximate): 300 discharge/charge cycles
  • Coin-cell battery: CR2032
  • Operating time: Varies depending on operating conditions and can significantly reduce under certain power-intensive conditions.
68 Whr LCL
  • Type: 68 Whr LCL
  • Voltage: 7.60 VDC
  • Weight (maximum): 0.34 kg (0.75 lb)
  • Dimensions:
  • Height: 95.90 mm (3.78 in.)
  • Width: 181 mm (7.13 in.)
  • Depth: 7.05 mm (0.28 in.)
  • Temperature range::
  • Operating: 0°C to 50°C (32°F to 122°F)
  • Storage: -20°C to 60°C (-4°F to 140°F)
  • Operating time: Varies depending on operating conditions and can significantly reduce under certain power-intensive conditions.
  • Charging time (approximate): 4 hours (when the computer is off)
  • Life span (approximate): 1000 discharge/charge cycles
  • Coin-cell battery: CR2032
  • Operating time: Varies depending on operating conditions and can significantly reduce under certain power-intensive conditions.

Camera (Web Cam) Specifications

Camera specifications
Number of cameras

One

Type

RGB, HD fixed focus

Location

Front Camera

Sensor type

CMOS sensor technology

Resolution:
Still image

Two megapixels

Video

HD resolution (1280 x 720) at 30 fps

Diagonal viewing angle

78.6 degrees

Audio Specifications

Audio specifications
Controller

Realtek ALC3204 with Waves MaxxAudio Pro

Stereo conversion

24-bit DAC (Digital-to-Analog) and ADC (Analog-to-Digital)

Internal interface

Intel HDA (high-definition audio)

External interface

Universal Audio Jack

Speakers

2

Speaker Output Average

2 W

Speaker Output Peak

2.5 W

Media-card Reader

Media-card reader specifications
Type

Micro SD-card slot

Cards supported
  • Micro Secure Digital (mSD)
  • Micro Secure Digital High Capacity (mSDHC)
  • Micro Secure Digital Extended Capacity (mSDXC)

Ports and connectors

External ports and connectors
External:
Network

One Flip-down RJ-45 port

USB
  • Two USB 3.1 Type-A port
  • One USB 3.1 Type-A with PowerShare port
  • One USB 3.1 Gen2 Type-C port with DisplayPort Alt Mode/Thunderbolt 3 (optional)
Audio

One headset (headphone and microphone combo) port

Video
  • One HDMI 1.4b port
  • One DisplayPort 1.2 port over USB Type-C
Power adapter port
  • 7.4 mm barrel-type
  • One PowerDelivery 3.0 port over USB Type-C
Security

One security-cable slot (wedge-shaped)

Card slot

microSD card slot

SIM card

uSIM card slot

Ports and connectors

Internal ports and connectors
Internal:
One M.2 Key-M (2280 or 2230) for solid-state drive One M.2 3042 Key-B for WWAN One M.2 2230 Key-E for WLAN
  • One M.2 2230 slot for solid-state drive 128 GB/256 GB/512 GB
  • One M.2 2280 slot for solid-state drive 256 GB/512 GB/1 TB
  • One M.2 2280 slot for Self-Encrypting solid-state drive 256 GB/512 GB

Communication wireless module

Ethernet specifications
Model number

Gigabit RJ-45

Transfer rate

10/100/1000 Mbps

Communication wireless module

Wireless module specifications
Qualcomm QCA61X4A
  • Model number: Qualcomm QCA61X4A
  • Transfer rate: Up to 867 Mbps
  • Frequency bands supported: 2.4 GHz/5 GHz
  • Wireless standards
    • WiFi 802.11a/b/g
    • Wi-Fi 4 (WiFi 802.11n)
    • Wi-Fi 5 (WiFi 802.11ac)
  • Encryption
    • 64-bit and 128-bit WEP
    • 128-bit AES-CCMP
    • TKIP
  • Bluetooth: 5
Intel Wi-Fi AX201
  • Model number: Intel Wi-Fi AX201
  • Transfer rate: Up to 2.4 Gbps
  • Frequency bands supported: 2.4 GHz/5 GHz
  • Wireless standards
    • WiFi 802.11a/b/g
    • Wi-Fi 4 (WiFi 802.11n)
    • Wi-Fi 5 (WiFi 802.11ac)
    • Wi-Fi 6 (WiFi 802.11 ax)
  • Encryption
    • 64-bit and 128-bit WEP
    • 128-bit AES-CCMP
    • TKIP
  • Bluetooth: 5.1
Intel XMM 7360 Global LTE-Advanced
  • Model number: Intel XMM 7360 Global LTE-Advanced
  • Transfer rate: Up to 450 Mbps
  • Frequency bands supported: 5 GHz
  • Wireless standards: 802.11ac
  • Encryption
    • 64-bit and 128-bit WEP
    • 128-bit AES-CCMP
    • TKIP
  • Bluetooth: No
Intel 9560 (For 8th generation Intel Core processors)
  • Model number: Intel 9560 (For 8th generation Intel Core processors)
  • Transfer rate: Up to 1733 Mbps
  • Frequency bands supported: 2.4 GHz/5 GHz
  • Wireless standards
    • WiFi 802.11a/b/g
    • Wi-Fi 4 (WiFi 802.11 n)
    • Wi-Fi 5 (WiFi 802.11 ac)
    • TBD
  • Encryption
    • 64-bit/128-bit WEP
    • AES-CCMP
    • TKIP
  • Bluetooth: 5
Intel AX200 (For 8th generation Intel Core processors)
  • Model number: Intel AX200 (For 8th generation Intel Core processors)
  • Transfer rate: Up to 2.4 Gbps
  • Frequency bands supported: 2.4 GHz/5 GHz
  • Wireless standards
    • WiFi 802.11a/b/g
    • Wi-Fi 4 (WiFi 802.11 n)
    • Wi-Fi 5 (WiFi 802.11 ac)
    • TBD
  • Encryption
    • 64-bit/128-bit WEP
    • AES-CCMP
    • TKIP
  • Bluetooth: 5.1

Security

Security specifications
Trusted Platform Module (TPM) 2.0 Integrated on system board
Fingerprint reader Optional
Wedge-shaped lock slot Standard

Security Software

Security Software specifications
Dell Client Command Suite
Optional Dell Data Security and Management Software Dell Client Command Suite Dell BIOS Verification Optional Dell Endpoint Security and Management Software VMware Carbon Black Endpoint Standard VMware Carbon Black Endpoint Standard + Secureworks Threat Detection and Response Dell Encryption Enterprise Dell Encryption Personal Carbonite VMware Workspace ONE Absolute® Endpoint Visibility and Control Netskope Dell Supply Chain Defense

Charger | Power Adapter

Power adapter specifications
65 W
  • Type: 65 W
  • Diameter (connector): 22 x 66 x 106 mm
  • Input voltage: 100 VAC x 240 VAC
  • Input frequency: 50 Hz x 60 Hz
  • Input current (maximum): 1.50 A
  • Output current (continuous): 3.34 A
  • Rated output voltage: 19.50 VDC
  • Temperature range:
  • Operating: 0°C to 40°C (32°F to 104°F)
  • Storage: -40°C to 70°C (-40°F to 158°F)
90 W
  • Type: 90 W
  • Diameter (connector): 22 x 66 x 130 mm
  • Input voltage: 100 VAC x 240 VAC
  • Input frequency: 50 Hz x 60 Hz
  • Input current (maximum): 1.60 A
  • Output current (continuous): 4.62 A
  • Rated output voltage: 19.50 VDC
  • Temperature range:
  • Operating: 0°C to 40°C (32°F to 104°F)
  • Storage: -40°C to 70°C (-40°F to 158°F)
65 W Type-C
  • Type: 65 W Type-C
  • Diameter (connector): 48.26 x 129.54 x 215.9 mm
  • Input voltage: 100 VAC x 240 VAC
  • Input frequency: 50 Hz x 60 Hz
  • Input current (maximum): 1.70 A
  • Output current (continuous): 4.62 A
  • Rated output voltage: 19.50 VDC
  • Temperature range:
  • Operating: 0°C to 40°C (32°F to 104°F)
  • Storage: -40°C to 70°C (-40°F to 158°F)
90 W Type-C
  • Type: 90 W Type-C
  • Diameter (connector): 43.18 x 177.8 x 215.9 mm
  • Input voltage: 100 VAC x 240 VAC
  • Input frequency: 50 Hz x 60 Hz
  • Input current (maximum): 1.70 A
  • Output current (continuous): 4.62 A
  • Rated output voltage: 19.50 VDC
  • Temperature range:
  • Operating: 0°C to 40°C (32°F to 104°F)
  • Storage: -40°C to 70°C (-40°F to 158°F)
VN:F [1.9.22_1171]
Rating: 0.0/10 (0 votes cast)

Related posts

Top
