Vostro 3405 Specs and Review 3000 Series AMD Athlon Silver

Dell Vostro 3405 – Overview

The Dell Vostro 3405 is 3000 Series laptop powered by AMD Athlon Silver 3050U Processor, AMD Radeon Vega 10 Graphics, with the support of up to 16 GB RAM and a M.2 2230 solid-state drive Storage. It has a Native Resolution: 1366 x 768 display screen. The maximum weight for the laptop is 1.70 kg (3.61 lb) and its equipped with 42 Whr 3 cell Polymer Battery in the base variant. The Vostro 3405 base price is USD $500 but can be customized adding more specs and features.

Vostro 3405 – Bottom View

Vostro 3405 – Display View

Vostro 3405 – Palmrest View

Vostro 3405 – Sides View

Dell Vostro 3405 – Specs

QuickSpecs
Brand	Dell
Series	Dell Vostro 3000
Model	Dell Vostro 3405
Price	Starting from $500
Color	Dune
Processor Generation	AMD Athlon Silver 3050U
Display Size	354.92 mm ( 13.97 in.)
Weight	1.70 kg (3.61 lb)
Battery	42 Whr 3 cell Polymer
Minimum RAM	4 GB
Maximum RAM	16 GB
Release Date	03 OCT 2021

Dell Vostro 3405 – Technical Specifications

Processor
OS
Chipset
RAM
Storage
Design
Display
Graphics
Battery
WebCam
Audio
Card Reader
Connectors
Wi-Fi
Keyboard
TouchPad
Charger

Processor Specifications

Processors
AMD Athlon Silver 3050U	Processors: AMD Athlon Silver 3050U Wattage: 15 W Core count: 2 Thread count: 2 Speed: Up to 3.2 GHz Cache: 4 MB Integrated graphics: AMD Radeon Graphics
AMD Athlon Gold 3150U	Processors: AMD Athlon Gold 3150U Wattage: 15 W Core count: 2 Thread count: 4 Speed: Up to 3.3 GHz Cache: 4 MB Integrated graphics: AMD Radeon Graphics
AMD Ryzen 3 3250U	Processors: AMD Ryzen 3 3250U Wattage: 15 W Core count: 2 Thread count: 4 Speed: Up to 3.5 GHz Cache: 4 MB Integrated graphics: AMD Radeon Graphics
AMD Ryzen 5 3450U	Processors: AMD Ryzen 5 3450U Wattage: 15 W Core count: 4 Thread count: 8 Speed: Up to 3.5 GHz Cache: 4 MB Integrated graphics: AMD Radeon Vega 8 Graphics
AMD Ryzen 5 3500U	Processors: AMD Ryzen 5 3500U Wattage: 15 W Core count: 4 Thread count: 8 Speed: Up to 3.7 GHz Cache: 4 MB Integrated graphics: AMD Radeon Vega 8 Graphics
AMD Ryzen 7 3700U	Processors: AMD Ryzen 7 3700U Wattage: 15 W Core count: 4 Thread count: 8 Speed: Up to 4.0 GHz Cache: 4 MB Integrated graphics: AMD Radeon Vega 10 Graphics

Operating System

Operating System
Operating System	Windows 10 Home (64-bit) Windows 10 Professional (64-bit)

Chipset

Chipset
Integrated	Chipset: Integrated Processor: AMD Athlon series Flash EPROM: 16 MB PCIe bus: Up to Gen 3
Integrated	Chipset: Integrated Processor: AMD Ryzen series Flash EPROM: 16 MB PCIe bus: Up to Gen 3

Memory (RAM)

Memory specifications
Slots	Two SODIMM
Type	DDR4
Speed	2400 MHz
Maximum memory	16 GB
Minimum memory	4 GB
Configurations supported	4 GB, 1 x 4 GB, DDR4, 2400MHz, SO-DIMM 8 GB, 2 x 4 GB, DDR4, 2400MHz, SO-DIMM 8 GB, 1 x 8 GB, DDR4, 2400MHz, SO-DIMM 12 GB, 1×8 GB + 1×4 GB, DDR4, 2400MHz, SO-DIMM 16 GB, 2 x 8 GB, DDR4, 2400MHz, SO-DIMM 16 GB, 1 x 16 GB, DDR4, 2400MHz, SO-DIMM

Storage

Storage specifications
2.5-in. 5400 rpm, hard drive	SATA, 2 TB
M.2 2230 solid-state drive	PCIe NVMe 3×4, Upto 512 GB
M.2 2280 solid-state drive	PCIe NVMe 3×4, Upto 1 TB

Dimensions and Weight

Dimensions and weight
Height:
Front	18.10 mm (0.71 in.)
Rear	19.90 mm (0.78 in.)
Width	328.70 mm (12.94 in.)
Depth	239.50 mm (9.42 in.)
Weight	1.70 kg (3.61 lb)

Display (Screen)

Display specifications
High Definition (HD)	Type: High Definition (HD) Panel technology: TN Luminance (typical): 220 nits Dimensions (Active Area): Height: 173.99 mm ( 6.85 in.) Width: 309.35 mm ( 12.17 in.) Diagonal: 354.92 mm ( 13.97 in.) Native Resolution: 1366 x 768 Megapixels: 1.05 M Pixels per Inch (PPI): 112 Color Gamut (CG): NTSC 45% Typ. Contrast Ratio (min): 400:1 Response Time (max): 16 ms Refresh Rate: 60 Hz Horizontal View Angle: 40 degrees (Left/Right) Vertical View Angle: 10 degrees (Up) / 30 degrees (Down) Pixel Pitch: 0.2265 x 0.2265 mm Power Consumption (maximum): 3.2 W Anti-glare vs glossy finish: Anti-glare Touch options: No
Full High Definition (FHD)	Type: Full High Definition (FHD) Panel technology: WVA Luminance (typical): 220 nits Dimensions (Active Area): Height: 173.99 mm ( 6.85 in.) Width: 309.35 mm ( 12.17 in.) Diagonal: 354.92 mm ( 13.97 in.) Native Resolution: 1920 x 1080 Megapixels: 2.07 M Pixels per Inch (PPI): 157 Color Gamut (CG): NTSC 45% Typ. Contrast Ratio (min): 500:1 Response Time (max): 35 ms Refresh Rate: 60 Hz Horizontal View Angle: 80 degrees (Left/Right) Vertical View Angle: 80 degrees (Up/Down) Pixel Pitch: 0.161 x 0.161 mm Power Consumption (maximum): 3.5 W Anti-glare vs glossy finish: Anti-glare Touch options: No

Video | Graphics (Integrated graphics)

Integrated graphics specifications
AMD Radeon Graphics	One HDMI port , Shared system memory AMD Athlon Gold/Silver AMD Ryzen 3
AMD Radeon Vega 8 Graphics	One HDMI port , Shared system memory AMD Ryzen 5
AMD Radeon Vega 10 Graphics	One HDMI port , Shared system memory AMD Ryzen 7

Battery Specifications

Battery specifications
Dimensions:
Type	42 Whr 3 cell Polymer battery
Voltage	11.40 VDC
Weight (maximum)	0.18 kg (0.40 lb)
Height	184.10 mm (7.25 in.)
Width	90.73 mm (3.57 in.)
Depth	5.75 mm (0.23 in.)
Charging time (approximate)	4 hours (when the computer is off)
Life span (approximate)	300 discharge/charge cycles
Coin-cell battery	CR2032

Camera (Web Cam) Specifications

Camera specifications
Resolution:
Number of cameras	One
Type	HD RGB camera
Location	Front Camera
Sensor type	CMOS sensor technology
Still image	0.92 megapixel
Video	1280 x 720 (HD) at 30 fps
Diagonal viewing angle	87 degrees

Audio Specifications

Audio specifications
Realtek ALC3204	Controller: Realtek ALC3204 Stereo conversion: Supported Internal interface: HDA (High definition audio) External interface: Audio jack Speakers: 2 Internal-speaker amplifier: Supported External volume controls: Keyboard shortcut controls Speaker Output Average: 2 W Speaker Output Peak: 2.5 W Subwoofer output: Not supported Microphone: Single digital microphone
Cirrus CS8409 Cirrus CS42L42 Cirrus TI SN005825	Controller Cirrus CS8409 Cirrus CS42L42 Cirrus TI SN005825 Stereo conversion: Supported Internal interface: HDA bridge + CS42L42 audio codec External interface: Audio jack Speakers: Two Internal-speaker amplifier: Supported External volume controls: Keyboard shortcut controls Speaker Output Average: 2 W Speaker Output Peak: 2.5 W Subwoofer output: Not supported Microphone: Single digital microphone

Media-card Reader

Media-card reader specifications
Type	One SD card
Cards supported	Secure Digital (SD) Secure Digital High Capacity(SDHC) Secure Digital Extended Capacity(SDXC)

Ports and connectors

External ports and connectors
External:
Network	One RJ 45 10/100 Mbps
USB	Two USB 3.2 Gen1 Type-A ports One USB 2.0 Type-A port
Audio	One Universal audio port (Computers with Realtek audio configuration) Two USB 3.2 Gen1 Type-A ports One Audio jack (Computers with Cirrus logic audio configuration)
Video	One HDMI 1.4 port
Power adapter port	4.5 mm barrel-type
Security	One Wedge shaped lock slot
Card slot	One SD card slot

Communication wireless module

Wireless module specifications
Model number	Qualcomm QCA61x4A
Transfer rate	Up to 867 Mbps
Frequency bands supported	2.4 GHz/5 GHz
Wireless standards	WiFi 802.11a/b/g Wi-Fi 4 (Wi-Fi 802.11n) Wi-Fi 5 (Wi-Fi 802.11ac Wave 2)
Encryption	64-bit/128-bit WEP AES-CCMP TKIP
Bluetooth	Bluetooth 5.0

keyboard

Keyboard specifications
Number of keys	102 (U.S. and Canada) 103 (UK) 106 (Japan)
Size	X= 18.6 mm (0.73 in.) key pitch Y= 19.05 mm (0.75 in.) key pitch
Backlit keyboard	Optional (backlit and Non-backlit)
Layout	QWERTY

TouchPad

Touchpad specifications
Touchpad resolution:
Horizontal	305
Vertical	305
Touchpad dimensions:
Horizontal	105 mm (4.13 in.)
Vertical	80 mm (3.15 in.)
Touchpad gestures	For more information about touchpad gestures available on Windows, see the Microsoft knowledge base article at .

Charger | Power Adapter

Power adapter specifications

Diameter (connector)	2.9 mm x 5.4 mm
Weight	0.23 kg (0.51 lb)
Input voltage	100 VAC x 240 VAC
Input frequency	50 Hz x 60 Hz
Input current (maximum)	1.30 A
Output current (continuous)	2.31 A
Rated output voltage	19.50 VDC
Operating	0°C to 40°C (32°F to 104°F)
Storage	-40°C to 70°C (-40°F to 158°F)
