Dell Latitude 15 5000 5500 Specs and Review Core i7-8665U

Dell Latitude 5500 – Review

The Latitude 5500 is 5000 Series laptop powered by 8th Gen Intel Core i7-8665U Processor, Intel UHD Graphics 620, with the support of up to 32 GB RAM and a M.2 2230 SSD, PCIe Gen 3×2 NVMe, Upto 512 GB storage. It has a 15.6 inch display screen. The maximum weight for the laptop is 1.82 kg (4.03 lb) and its equipped with 3-cell lithium-ion (42 WHr) ExpressCharge battery in the base variant. The Latitude 5500 base price is US$750 but can be customized adding more specs and features.

Latitude 5500 - Display View

Latitude 5500 – Display View

Latitude 5500 - Bottom View

Latitude 5500 – Bottom View

Latitude 5500 - Palmerst View

Latitude 5500 – Palmerst View

Dell Latitude 5500 – Specs

QuickSpecs
Brand Dell
Series Dell Latitude 5000
Model Dell Latitude 5500
Price Starting from US$750
Color Black
Processor Generation 8th Gen Intel Core i7-8665U
Display Size 15.6 inch/td>
Weight 1.82 kg (4.03 lb)
Battery 3-cell lithium-ion (42 WHr) ExpressCharge
Minimum RAM 4 GB
Maximum RAM 32 GB
Release Date 30 APR 2019

Dell Latitude 5500 – Technical Specifications

Processor Information

System information
Chipset Integrated in the processor
DRAM bus width 64-bit
FLASH EPROM 32 MB
PCIe bus Up to Gen3
External bus frequency Up to 8 GT/s

Processor Specifications

Processor specifications
8th Gen Intel Core i7-8665U processor (8 MB cache, 4 core count/8 threads, 1.9 GHz to 4.8 GHz, 15 W TDP, vPro) Intel UHD Graphics 620, AMD Radeon 540X
8th Gen Intel Core i5-8365U processor (6 MB cache, 4 core count/8 threads, 1.6 GHz to 4.1 GHz, 15 W TDP, vPro) Intel UHD Graphics 620, AMD Radeon 540X
8th Gen Intel Core i5-8265U processor (6 MB cache, 4 core count/8 threads, 1.6 GHz to 3.9 GHz, 15 W TDP) Intel UHD Graphics 620, AMD Radeon 540X
8th Gen Intel Core i3-8145U processor (4 MB cache, 2 core count/4 threads, 2.1 GHz to 3.9 GHz, 15 W TDP) Intel UHD Graphics 620, NA

Operating System

Operating system
Operating systems supported
  • Windows 10 Home (64 bit)
  • Windows 10 Professional (64bit)
  • Ubuntu 18.04 LTS (64 bit)

Memory (RAM)

Memory specifications
Minimum memory configuration 4 GB
Maximum memory configuration 32 GB
Number of slots 2 x SoDIMM slots
Maximum memory supported per slot 16 GB
Memory options
  • 4 GB (1 x 4 GB)
  • 8 GB (2 x 4 GB)
  • 8 GB (1 x 8 GB)
  • 16 GB (2 x 8 GB)
  • 16 GB (1 x 16 GB)
  • 32 GB (2 x 16 GB)
Type Dual-channel DDR4
Speed

2666 MHz Non-ECC SDRAM operates at 2400 MHz with Intel 8th Gen processors

Storage

Storage specifications
PCIe Solid-State Drive M.2 2230 SSD, PCIe Gen 3×2 NVMe, up to 32 Gbps, Upto 512 GB
PCIe Solid-State Drive M.2 2280 SSD, PCIe Gen 3×4 NVMe, up to 32 Gbps, Upto 1 TB
SATA Solid-State Drive M.2 2280 SSD, SATA Class 20, Upto 512 GB
SED PCIe Solid-State Drive M.2 2280 SSD, SED PCIe, Upto 512 GB
HDD 2.5 in., SATA

  • Upto 1 TB; 5400 RPM
  • Upto 1 TB; 7200 RPM

Dimensions and Weight

Dimensions and weight
Height

Front: 20.3 mm (0.79 in.)

Rear: 22 mm (0.86 in.)

Width

359.1 mm (14.1 in.)

Depth

236.25 mm (9.3 in.)

Weight

1.82 kg (4.03 lb)

Display (Screen)

Display specifications
Type
  • 15.6 in. HD (1366 x 768), antiglare (16:9), WLED, non-touch, 220 nits
  • 15.6 in. FHD Wide viewing angle (1920 x 1080), antiglare (16:9) WLED, non-touch, 220 nits
  • 15.6 in. FHD Wide viewing angle (1920 x 1080), Embedded touch display with antiglare, 220 nits (optional)
  • 15.6 in. FHD Wide viewing angle (1920 x 1080), antiglare (16:9) WLED, non-touch, 300 nits, aluminum LCD backcover (optional)
  • 15.6 in. FHD Wide viewing angle (1920 x 1080), Embedded touch display with antiglare, 220 nits, aluminum LCD backcover (optional)
Height (Active area)

193.6 mm (7.622 in.)

Width (Active area)

344.2 mm (13.551 in.)

Diagonal

394.91 mm (15.55 in.)

Pixels Per Inch (PPI)

100

141 (optional)

Contrast ratio

500:1 (Typ.)

700:1 (Typ.) (optional)

Luminance/Brightness (typical)

220 Nits

300 Nits

Refresh rate

60 Hz

Horizontal viewing angle (min)

+/- 40 degrees (HD)

+/- 80 degrees (FHD) (optional)

Vertical viewing angle (min)

top/bottom = 10/30 degrees (HD)

+/- 80 degrees (FHD)(optional)

Power consumption (max)

4.2 W

6.2 W (optional)

Video | Graphics

Video card specifications
Intel UHD Graphics 620 UMA

  • Intel Core i7-8665U CPU (vPro)
  • Intel Core i5-8365U CPU
  • Intel Core i5-8265U CPU
  • Intel Core i3-8145U CPU

, Integrated, Shared system memory, HDMI 1.4b port, 4096 x 2304 @24 Hz

AMD Radeon 540X Discrete, NA, GDDR5, 2 GB, N/A, N/A

Battery Specifications

Battery
3-cell lithium-ion (42 WHr) ExpressCharge
  • Type: 3-cell lithium-ion (42 WHr) ExpressCharge
  • Dimension: WidthDepthHeight
  • Weight (maximum): 200 g (0.44 lb)
  • Voltage: 11.40 VDC
  • Life span: 300 discharge/charge cycles
  • Charging time when the computer is off (approximate): Standard charge
  • Express Charge: 0°C to 15°C: 4 hours 16°C to 45°C: 2 hours 46°C to 50°C: 3 hours
  • Operating time: Varies depending on operating conditions and can significantly reduce under certain power-intensive conditions.
  • Temperature range: Operating: Charge: 0°C to 50°C, 32°F to 122°FDischarge: 0°C to 60°C, 32°F to 139°F
  • Temperature range: Storage: -20°C to 60°C (-4°F to 140°F)
  • Coin-cell battery: CR-2032
3-cell lithium-ion (51 WHr) ExpressCharge
  • Type: 3-cell lithium-ion (51 WHr) ExpressCharge
  • Dimension: 95.9 mm (3.78 in.)181 mm (7.13 in.)7.05 mm (0.28 in.)
  • Weight (maximum): 250 g (0.55 lb)
  • Voltage: 11.40 VDC
  • Life span: 300 discharge/charge cycles
  • Charging time when the computer is off (approximate): 0°C to 50°C: 4 hours
  • Express Charge: Express Charge
  • Operating time: Varies depending on operating conditions and can significantly reduce under certain power-intensive conditions.
  • Temperature range: Operating: Charge: 0°C to 50°C (32°F to 122°F)Discharge: -20°C to 60°C (-40°F to 139°F)
  • Temperature range: Storage: -20°C to 60°C (-40°F to 140°F)
  • Coin-cell battery: CR-2032
4-cell lithium-ion (68 WHr) ExpressCharge
  • Type: 4-cell lithium-ion (68 WHr) ExpressCharge
  • Dimension: WidthDepthHeight
  • Weight (maximum): 340 g (0.75 lb)
  • Voltage: 7.6 VDC
  • Life span: 300 discharge/charge cycles (standard pack)1000 discharge/charge cycles (LCL pack)
  • Charging time when the computer is off (approximate): Standard charge
  • Express Charge: 0°C to 15°C: 4 hours 16°C to 45°C: 2 hours 46°C to 50°C: 3 hours
  • Operating time: Varies depending on operating conditions and can significantly reduce under certain power-intensive conditions.
  • Temperature range: Operating: Charge: 0°C to 50°C, 32°F to 122°FDischarge: 0°C to 60°C, 32°F to 139°F
  • Temperature range: Storage: -20°C to 60°C (-4°F to 140°F)
  • Coin-cell battery: CR-2032

Audio Specifications

Audio specifications
Controller

Realtek ALC3204 with Waves MaxxAudio Pro

Stereo conversion

24-bit DAC (Digital-to-Analog) and ADC (Analog-to-Digital)

Type

HD Audio

Speakers

Two

Interface
  • Intel HDA (high-definition audio)
  • 7.1 channel output via HDMI
  • Digital microphone input on camera module
  • Headset combo jack (stereo headphones/microphone-in)
Internal speaker amplifier

Integrated in ALC3204 (Class-D 2 W)

External volume controls

Media-control shortcut keys

Speaker output:

Average: 2 W

Peak: 2.5 W

Microphone

Digital-array microphones

Ports and connectors

Ports and connectors
Memory card reader
  • One MicroSD card reader
SIM card reader

One micro SIM card slot

USB
  • Three USB 3.1 Gen 1 (Type-A) ports
  • One USB Type-C 3.1 Gen 2 port with DisplayPort/Thunderbolt 3(optional)
Security Noble wedge lock slot
Audio

One headset (headphone and microphone combo) port

Video

One HDMI 1.4b port (supports up to 4k @30 Hz)

Network adapter

RJ-45, 10/100/1000, with LED indicator

Communication wireless module

Communication specifications
Network adapter
  • 8th Generation Intel® Core i5-8365U
  • 8th Generation Intel® Core i7-8665U
  • 8th Generation Intel® Core i3-8145U
  • 8th Generation Intel® Core i5-8265U

keyboard

Keyboard specifications
Number of keys
  • 102 (U.S. and Canada)
  • 103 (UK)
  • 106 (Japan)
Size
  • X= 18.6 mm (0.73 in.) key pitch
  • Y= 19.05 mm (0.75 in.) key pitch
Backlit keyboard

Optional (backlit and Non-backlit)

Layout

QWERTY

TouchPad

Touchpad specifications
Resolution

1221 x 661

Dimensions
  • Width: 101.7 mm (4.00 in.)
  • Height: 55.2 mm (2.17 in.)
Multi-touch

Supports 5-finger multi-touch

Security

Security
Trusted Platform Module (TPM) 2.0

Integrated on the system board

Firmware TPM

Optional

Windows Hello Support

Yes, optional fingerprint on power button

Optional IR camera

Cable lock

Noble lock

Dell Smartcard Keyboard

Optional

FIPS 140-2 certification for TPM

Yes

ControlVault 3 Advanced Authentication with FIPS 140-2 Level 3 Certification

Yes, for FPR, SC and CSC/NFC

Fingerprint Reader Only

Touch Fingerprint reader in power button tied to ControlVault 3

Contacted Smart Card and ControlVault 3

FIPS 201 Smart card reader certification/SIPR

Security Software

Security Software specifications
Dell Client Command Suite
Optional Dell Data Security and Management Software Dell Endpoint Security Suite Enterprise Dell Data Guardian Dell Encryption Enterprise Dell Encryption Personal Dell Threat Defense MozyPro or MozyEnterprise RSA NetWitness Endpoint RSA SecurID Access VMware Workspace ONE Absolute Endpoint Visibility and Control

Charger | Power Adapter

Power adapter specifications
E5 65 W
  • Type: E5 65 W
  • Input Voltage: 100 VAC – 240 VAC
  • Input current (maximum): 1.5 A
  • Adapter size: DimensionsIn Inches: 0.87 x 2.60 x 4.17In mm: 22 x 66 x 106
  • Barrel: 7.4 mm
  • Weight: 0.23 kg (0.51 lb)
  • Input frequency: 50 Hz to 60 Hz
  • Output current: 3.34 A (continuous)
  • Rated output voltage: 19.5 VDC
  • Temperature range (Operating): 0°C to 40°C (32°F to 104°F)
  • Temperature range (Non-Operating): -40°C to 70°C (-40°F to 158°F)
E5 90 W
  • Type: E5 90 W
  • Input Voltage: 100 VAC – 240 VAC
  • Input current (maximum): 1.6 A
  • Adapter size: DimensionsIn Inches: 0.87 x 2.60 x 5.12In mm: 22 x 66 x 130
  • Barrel: 7.4 mm
  • Weight: 0.32 kg (0.70 lb)
  • Input frequency: 50 Hz to 60 Hz
  • Output current: 4.62 A (continuous)
  • Rated output voltage: 19.5 VDC
  • Temperature range (Operating): 0°C to 40°C (32°F to 104°F)
  • Temperature range (Non-Operating): -40°C to 70°C (-40°F to 158°F)
