Dell Vostro 15 3510 15.6 inch 10th and 11th Generation

Dell Vostro 15 3510 Review

The Dell Vostro 15 3510 is 15.5 inch 3000 Series laptop powered by 10th Generation Intel Core i3-1005G1 Processor, Intel UHD Graphics Intel 10th Generation Core i3/i5 processors with the support of up to DDR4 16 GB RAM having speed of 2666 MHz and a M.2 2230 solid-state drive upto 1 TB storage. It has a High Definition (HD) TN (Twisted Nematic) display screen with resolution: 1366 x 768. The maximum weight of the laptop is 1.69 kg (3.72 lb) and its equipped with 3-cell, 41 Wh, lithium-polymer in the base variant. The Vostro 15 3510 base price is USD $599 but can be customized adding more specs and features.

Vostro 15 3510 - Bottom View

Vostro 15 3510 – Bottom View

Vostro 15 3510 - Front View

Vostro 15 3510 – Front View

Vostro 15 3510 - Side Views

Vostro 15 3510 – Side Views

Vostro 15 3510 - Top View

Vostro 15 3510 – Top View

Dell Vostro 15 3510 – Specs

QuickSpecs
Brand Dell
Series DellVostro 3000
Model Dell Vostro 15 3510
Price Starting from $599
Color Titan Grey
Processor Generation 10th Generation Intel Core i3-1005G1
Display Size 394.90 mm (15.54 in.)
Weight 1.69 kg (3.72 lb)
Battery 3-cell, 41 Wh, lithium-polymer
Minimum RAM 4 GB
Maximum RAM 16 GB
Release Date 30 SEP 2021

Dell Vostro 15 3510 – Technical Specifications

Processor Specifications

Processor
Intel Celeron 6305
  • Processor type: Intel Celeron 6305
  • Processor wattage: 15 W
  • Processor core count: 2
  • Processor thread count: 2
  • Processor speed: Up to 1.8 GHz
  • Processor cache: 4 MB
  • Integrated graphics: Intel UHD Graphics
Intel Pentium 7505
  • Processor type: Intel Pentium 7505
  • Processor wattage: 15 W
  • Processor core count: 2
  • Processor thread count: 4
  • Processor speed: 2.00 GHz to 3.5 GHz
  • Processor cache: 4 MB
  • Integrated graphics: Intel UHD Graphics
10th Generation Intel Core i3-1005G1
  • Processor type: 10th Generation Intel Core i3-1005G1
  • Processor wattage: 15 W
  • Processor core count: 2
  • Processor thread count: 4
  • Processor speed: 1.20 GHz to 3.40 GHz
  • Processor cache: 4 MB
  • Integrated graphics: Intel UHD Graphics
10th Generation Intel Core i5-1035G1
  • Processor type: 10th Generation Intel Core i5-1035G1
  • Processor wattage: 15 W
  • Processor core count: 4
  • Processor thread count: 8
  • Processor speed: 1.00 GHz to 3.60 GHz
  • Processor cache: 6 MB
  • Integrated graphics: Intel UHD Graphics
11th Generation Intel Core i3-1115G4
  • Processor type: 11th Generation Intel Core i3-1115G4
  • Processor wattage: 15 W
  • Processor core count: 2
  • Processor thread count: 4
  • Processor speed: 3.00 GHz to 4.10 GHz
  • Processor cache: 6 MB
  • Integrated graphics: Intel UHD Graphics
11th Generation Intel Core i3-1125G4
  • Processor type: 11th Generation Intel Core i3-1125G4
  • Processor wattage: 15 W
  • Processor core count: 4
  • Processor thread count: 8
  • Processor speed: 2.00 GHz to 3.70 GHz
  • Processor cache: 8 MB
  • Integrated graphics: Intel UHD Graphics
11th Generation Intel Core i5-1135G7
  • Processor type: 11th Generation Intel Core i5-1135G7
  • Processor wattage: 15 W
  • Processor core count: 4
  • Processor thread count: 8
  • Processor speed: 2.40 GHz to 4.20 GHz
  • Processor cache: 8 MB
  • Integrated graphics: Intel Iris Xe Graphics
11th Generation Intel Core i7-1165G7
  • Processor type: 11th Generation Intel Core i7-1165G7
  • Processor wattage: 15 W
  • Processor core count: 4
  • Processor thread count: 8
  • Processor speed: 2.80 GHz to 4.70 GHz
  • Processor cache: 12 MB
  • Integrated graphics: Intel Iris Xe Graphics

Operating System

Operating System
Operating System
  • Windows 11 Home, 64-bit
  • Windows 11 Home National Academic, 64-bit
  • Windows 11 Home in S-mode, 64-bit
  • Windows 11 Pro, 64-bit
  • Windows 10 Home, 64-bit
  • Windows 10 Pro, 64-bit
  • Windows 10 Pro, 64-bit
  • Windows 10 Home in S-mode, 64-bit
  • Ubuntu 20.04 LTS, 64-bit

Chipset

Chipset
Intel Core i3/i5/i7 Intel Celeron / Pentium
  • Processors
    • Intel Core i3/i5/i7
    • Intel Celeron / Pentium
  • Chipset: Intel Tiger Lake (Integrated in the processor)
  • DRAM bus width: 64-bit
  • Flash EPROM: 16 MB + 8 MB
  • PCIe bus: Up to Gen 3
Intel Core i3 / i5
  • Processors: Intel Core i3 / i5
  • Chipset: Intel Ice Lake (Integrated in the processor)
  • DRAM bus width: 64-bit
  • Flash EPROM: 16 MB + 8 MB
  • PCIe bus: Up to Gen 3

Memory (RAM)

Memory specifications
Memory slots

Two SODIMM slots

Memory type

DDR4

Memory speed
  • 2666 MHz (With Integrated Graphics)
  • 3200 Mhz (With Discrete Graphics)
Maximum memory configuration

16 GB

Minimum memory configuration

4 GB

Memory size per slot

4 GB, 8 GB, 16 GB

Memory configurations supported
  • 4 GB, 1 x 4 GB, DDR4, 2666 MHz/3200 MHz
  • 8 GB, 1 x 8 GB, DDR4, 2666 MHz/3200 MHz
  • 8 GB, 2 x 4 GB, DDR4, 2666 MHz/3200 MHz
  • 12 GB, 1 x 4 GB + 1 x 8 GB, DDR4, 2666 MHz/3200 MHz
  • 16 GB, 2 x 8 GB, DDR4, 2666 MHz/3200 MHz
  • 16 GB, 1 x 16 GB, DDR4, 2666 MHz/3200 MHz

Storage

Storage specifications
2.5-inch 5400 rpm, hard drive SATA, upto 2 TB
M.2 2230 solid-state drive PCIe NVMe 3×4, upto 1 TB
M.2 2280 solid-state drive PCIe NVMe 3×4, upto 2 TB

Storage Configuration

Storage Configuration
Storage
  • with a 2.5-inch hard-drive, the 2.5-inch hard-drive is the primary drive
  • with a M.2 2230/2280 drive, the M.2 2230/2280 drive is the primary drive
  • with a 2.5-inch hard-drive and one M.2 2230/2280 solid-state drive, the M.2 2230/2280 solid-state drive is the primary drive

Dimensions and Weight

Dimensions and weight
Height:
Front height

17.50 mm (0.68 in.)

Rear height

18.90 mm (0.74 in.)

Width

358.50 mm (14.11 in.)

Depth

235.56 mm (9.27 in.)

Starting weight

1.69 kg (3.72 lb)

Display (Screen)

Display specifications
High Definition (HD)
  • Display type: High Definition (HD)
  • Display-panel technology: TN (Twisted Nematic)
  • Display-panel dimensions (active area):
  • Height: 193.54 mm (7.62 in.)
  • Width: 344.23 mm (13.55 in.)
  • Diagonal: 394.90 mm (15.54 in.)
  • Display-panel native resolution: 1366 x 768
  • Luminance (typical): 220 nits
  • Megapixels: 1.05
  • Color gamut: NTSC 45% Typ.
  • Pixels Per Inch (PPI): 100
  • Contrast ratio (min.): 400:1
  • Response time (max.): 25 ms
  • Refresh rate: 60 Hz
  • Horizontal view angle (min.): 40 +/- degrees
  • Vertical view angle (min.): 10(Top)/30(Bottom) degrees
  • Pixel pitch: 0.252 mm
  • Power consumption (maximum): 4.2 W
  • Anti-glare vs glossy finish: Anti-glare
  • Touch options: No
Full High Definition (FHD)
  • Display type: Full High Definition (FHD)
  • Display-panel technology: WVA (wide view angle)
  • Display-panel dimensions (active area):
  • Height: 193.54 mm (7.62 in.)
  • Width: 344.23 mm (13.55 in.)
  • Diagonal: 394.90 mm (15.54 in.)
  • Display-panel native resolution: 1920 x 1080
  • Luminance (typical): 220 nits
  • Megapixels: 2.07
  • Color gamut: NTSC 45% Typ.
  • Pixels Per Inch (PPI): 141
  • Contrast ratio (min.): 400:1
  • Response time (max.): 35 ms
  • Refresh rate: 60 Hz
  • Horizontal view angle (min.): 80 +/- degrees
  • Vertical view angle (min.): 80 +/- degrees
  • Pixel pitch: 0.179 mm
  • Power consumption (maximum): 4.2 W
  • Anti-glare vs glossy finish: Anti-glare
  • Touch options: No

GPU — Integrated

GPU—Integrated
Intel UHD Graphics Shared system memory

  • Intel 10th Generation Core i3/i5 processors
  • Intel 11th Generation Core i3 processors
  • Intel 11th Generation Celeron processors
  • Intel 11th Generation Pentium processors
Intel Iris Xe Graphics Shared system memory

  • Intel 11th Generation Core i5 / i7 processors

GPU — Discrete

GPU—Discrete
Nvidia GeForce MX350 Graphics 2 GB, GDDR5

Battery Specifications

Battery specifications
3-cell, 41 Wh, lithium-polymer
  • Battery type: 3-cell, 41 Wh, lithium-polymer
  • Battery voltage: 11.25 VDC
  • Battery weight (maximum): 0.19 kg (0.41 lb)
  • Battery dimensions:
  • Height: 206.4 mm (8.12 in.)
  • Width: 82 mm (3.22 in.)
  • Depth: 5.75 mm (0.22 in.)
  • Battery charging time (approximate): 4 hours (when the computer is off)
4-cell, 54 Wh, lithium-polymer
  • Battery type: 4-cell, 54 Wh, lithium-polymer
  • Battery voltage: 15.0 VDC
  • Battery weight (maximum): 0.24 kg (0.55 lbs)
  • Battery dimensions:
  • Height: 271.90 mm (10.70 in.)
  • Width: 82 mm (3.22 in.)
  • Depth: 5.75 mm (0.22 in.)
  • Battery charging time (approximate): 4 hours (when the computer is off)

Camera (Web Cam) Specifications

Camera specifications
Number of cameras

One

Camera type

RGB HD camera

Camera location

Front

Camera sensor type

CMOS sensor technology

Camera resolution:
Still image

0.92 megapixel

Video

1280 x 720 (HD @ 30 fps)

Diagonal viewing angle:

78.6 degrees

Audio Specifications

Audio specifications
Realtek ALC3204
  • Controller: Realtek ALC3204
  • Stereo conversion: Supported
  • Internal interface: High definition audio
  • External interface: One Headset jack
  • Speakers: Two
  • Internal-speaker amplifier: Supported
  • External volume controls: Keyboard shortcut controls
  • Speaker Output Average: 2 W
  • Speaker Output Peak: 2.5 W
  • Subwoofer output: Not supported
  • Microphone: Single digital microphone
Cirrus CS8409 (CS42L42 + TI SN005825)
  • Controller: Cirrus CS8409 (CS42L42 + TI SN005825)
  • Stereo conversion: Supported
  • Internal interface: HDA bridge + CS42L42 audio codec
  • External interface: Headset jack
  • Speakers: Two
  • Internal-speaker amplifier: Supported
  • External volume controls: Keyboard shortcut controls
  • Speaker Output Average: 2 W
  • Speaker Output Peak: 2.5 W
  • Subwoofer output: Not supported
  • Microphone: Single digital microphone

Media-card Reader

Media-card reader specifications
Media-card type

One SD 3.0 card

Media-cards supported
  • Secure Digital (SD)
  • Secure Digital High Capacity (SDHC)
  • Secure Digital Extended Capacity (SDXC)

Internal slots

Internal slots
M.2
  • One M.2 2230 slot for Wi-Fi and Bluetooth card
  • One M.2 2230/2280 slot for solid-state drive

External Ports

External ports
Network port

One Flip-down RJ 45 10/100/1000 Mbps

USB ports
  • Two USB 3.2 Gen 1 ports
  • One USB 3.2 Gen 1 Type-C port (optional with discrete graphics)
  • One USB 2.0 port
Audio port

One Headset jack

Video port

One HDMI 1.4 port

Media-card reader

One SD-card slot

Power-adapter port

4.5 mm barrel-type

Security-cable slot

One wedge-shaped lock slot

Communication wireless module

Wireless module specifications
Intel 9462
  • Model number: Intel 9462
  • Transfer rate: Up to 433 Mbps
  • Frequency bands supported: 2.4 GHz/5 GHz
  • Wireless standards
    • WiFi 802.11a/b/g
    • Wi-Fi 4 (Wi-Fi 802.11n)
    • Wi-Fi 5 (Wi-Fi 802.11ac)
  • Encryption
    • 64-bit/128-bit WEP
    • AES-CCMP
    • TKIP
  • Bluetooth: Bluetooth 5.0
Qualcomm QCNFA435 (DW1810)
  • Model number: Qualcomm QCNFA435 (DW1810)
  • Transfer rate: Up to 433 Mbps
  • Frequency bands supported: 2.4 GHz/5 GHz
  • Wireless standards
    • WiFi 802.11a/b/g
    • Wi-Fi 4 (Wi-Fi 802.11n)
    • Wi-Fi 5 (Wi-Fi 802.11ac)
  • Encryption
    • 64-bit/128-bit WEP
    • AES-CCMP
    • TKIP
  • Bluetooth: Bluetooth 4.1
Realtek RTL8821CE
  • Model number: Realtek RTL8821CE
  • Transfer rate: Up to 433 Mbps
  • Frequency bands supported: 2.4 GHz
  • Wireless standards
    • Wi-Fi 802.11 b/g
    • Wi-Fi 4 (WiFi 802.11n)
    • Wi-Fi 5 (Wi-Fi 802.11ac)
  • Encryption
    • 64-bit/128-bit WEP
    • AES-CCMP
    • TKIP
  • Bluetooth: Bluetooth 5.0
Intel AX201
  • Model number: Intel AX201
  • Transfer rate: Up to 2400 Mbps
  • Frequency bands supported: 2.4 GHz/5 GHz
  • Wireless standards
    • WiFi 802.11a/b/g
    • Wi-Fi 4 (WiFi 802.11n)
    • Wi-Fi 5 (WiFi 802.11ac)
    • Wi-Fi 6 (WiFi 802.11ax)
  • Encryption
    • 64-bit/128-bit WEP
    • AES-CCMP
    • TKIP
  • Bluetooth: Bluetooth 5.1

keyboard

Keyboard specifications
Keyboard type
  • Standard keyboard
  • White backlight keyboard
Keyboard layout

QWERTY

Number of keys
  • United States and Canada: 99 keys
  • United Kingdom: 100 keys
  • Japan: 103 keys
Keyboard size

X=18.70 mm key pitch

Y=18.05 mm key pitch

Keyboard shortcuts

Some keys on your keyboard have two symbols on them. These keys can be used to type alternate characters or to perform secondary functions. To type the alternate character, press Shift and the desired key. To perform secondary functions, press Fn and the desired key.

TouchPad

Touchpad specifications
Touchpad resolution:
Horizontal

> 300 DPI

Vertical

> 300 DPI

Touchpad dimensions:
Horizontal

115 mm (4.52 in.)

Vertical

80 mm (3.14 in.)

Fingerprint Reader

Fingerprint reader specifications
Fingerprint-reader sensor technology

Capacitive

Fingerprint-reader sensor resolution

500 dpi

Fingerprint-reader sensor pixel size

108 x 88

Charger | Power Adapter

Power adapter specifications
Type

65 W

Connector dimensions:
  • External diameter: 4.50 mm
  • Internal diameter: 2.90 mm
Input voltage

100 VAC x 240 VAC

Input frequency

50 Hz x 60 Hz

Input current (maximum)

1.70 A

Output current (continuous)

3.34 A

Rated output voltage

19.50 VDC

VN:F [1.9.22_1171]
Rating: 0.0/10 (0 votes cast)
Summary
product image
Author Rating
1star1star1star1stargray
Aggregate Rating
4 based on 1 votes
Brand Name
Dell
Product Name
Dell Vostro 15 3510 15.6 inch 10th and 11th Generation Laptop
Price
USD 599
Product Availability
Available in Stock

Related posts

Top
