Dell XPS 13 9380 13.3 inch 8th Gen Core i3 SSD, LPDDR3 RAM

• Processors: 8th Generation Intel Core i3 (8145U)
• Wattage: 15 W
• Core count: 2
• Thread count: 4
• Speed: 2.10 GHz, up to 3.90 GHz
• Smart cache: 4 MB
• Integrated graphics: Intel UHD Graphics 620

• Processors: 8th Generation Intel Core i5 (8265U)
• Wattage: 15 W
• Core count: 4
• Thread count: 8
• Speed: 1.60 GHz, up to 3.90 GHz
• Smart cache: 6 MB
• Integrated graphics: Intel UHD Graphics 620

• Processors: 8th Generation Intel Core i7 (8565U)
• Wattage: 15 W
• Core count: 4
• Thread count: 8
• Speed: 1.80 GHz, up to 4.60 GHz
• Smart cache: 8 MB
• Integrated graphics: Intel UHD Graphics 620

• Processors: 8th Generation Intel Core i5 (8365U)
• Wattage: 15 W
• Core count: 4
• Thread count: 8
• Speed: 1.60 GHz, up to 4.10 GHz
• Smart cache: 6 MB
• Integrated graphics: Intel UHD Graphics 620

• Processors: 8th Generation Intel Core i7 (8665U)
• Wattage: 15 W
• Core count: 4
• Thread count: 8
• Speed: 1.90 GHz, up to 4.80 GHz
• Smart cache: 8 MB
• Integrated graphics: Intel UHD Graphics 620

• Windows 10 Home (64-bit)
• Windows 10 Professional (64-bit)
• Ubuntu

• Processor: 8th generation Intel Core i3
• Chipset: Integrated in processor
• DRAM bus width: 64-bit per channel
• Flash EPROM: 32 MB
• PCIe bus: PCIe Gen 3
• External bus frequency: PCIe Gen 3×4

• Processor: 8th generation Intel Core i5
• Chipset: Integrated in processor
• DRAM bus width: 64-bit per channel
• Flash EPROM: 32 MB
• PCIe bus: PCIe Gen 3
• External bus frequency: PCIe Gen 3×4

• Processor: 8th generation Intel Core i7
• Chipset: Integrated in processor
• DRAM bus width: 64-bit per channel
• Flash EPROM: 32 MB
• PCIe bus: PCIe Gen 3
• External bus frequency: PCIe Gen 3×4

Onboard memory

Dual-channel LPDDR3

2133 MHz

16 GB

4 GB

Not applicable

• 4 GB LPDDR3 at 2133 MHz (2 x 2 GB)
• 8 GB LPDDR3 at 2133 MHz (2 x 4 GB)
• 16 GB LPDDR3 at 2133 MHz (2 x 8 GB)

• SATA AHCI, Up to 6 Gbps
• PCIe Gen 3 x4 NVMe, Up to 32 Gbps

• 2280: Up to 2 TB
• 2230: Up to 128 GB

7.80 mm (0.31 in.)

11.63 mm (0.46 in.)

301.76 mm (11.88 in.)

199.24 mm (7.84 in.)

1.27 kg (2.81 lb)

• Type: 13.3-inch FHD touchscreen
• Panel technology: Wide Viewing Angle (WVA)
• Luminance (typical): 400 nits
• Dimensions (active area):
• Height: 165.24 mm (6.51 in.)
• Width: 293.76 mm (11.57 in.)
• Diagonal: 337.82 mm (13.30 in.)
• Native resolution: 1920 x 1080
• Megapixels: 2.07
• Pixels per inch (PPI): 166
• Contrast ratio (min): 1500:1
• Response time (max): 30 msec rise/fall
• Refresh rate: 60 Hz
• Horizontal view angle: +/- 85 degrees
• Vertical view angle: +/- 85 degrees
• Pixel pitch: 0.153 mm
• Power consumption (maximum): 2.90 W
• Anti-glare vs Anti-reflective: Anti-reflective
• Touch options: Yes

• Type: 13.3-inch FHD non-touchscreen
• Panel technology: Wide Viewing Angle (WVA)
• Luminance (typical): 400 nits
• Dimensions (active area):
• Height: 165.24 mm (6.51 in.)
• Width: 293.76 mm (11.57 in.)
• Diagonal: 337.82 mm (13.30 in.)
• Native resolution: 1920 x 1080
• Megapixels: 2.07
• Pixels per inch (PPI): 166
• Contrast ratio (min): 1500:1
• Response time (max): 30 msec rise/fall
• Refresh rate: 60 Hz
• Horizontal view angle: +/- 85 degrees
• Vertical view angle: +/- 85 degrees
• Pixel pitch: 0.153 mm
• Power consumption (maximum): 2.90 W
• Anti-glare vs Anti-reflective: Anti-glare
• Touch options: No

• Type: 13.3-inch UHD touchscreen
• Panel technology: Wide Viewing Angle (WVA)
• Luminance (typical): 400 nits
• Dimensions (active area):
• Height: 165.24 mm (6.51 in.)
• Width: 293.76 mm (11.57 in.)
• Diagonal: 337.82 mm (13.30 in.)
• Native resolution: 3840 x 2160
• Megapixels: 8.29
• Pixels per inch (PPI): 331
• Contrast ratio (min): 1500:1
• Response time (max): 30 msec rise/fall
• Refresh rate: 60 Hz
• Horizontal view angle: +/- 85 degrees
• Vertical view angle: +/- 85 degrees
• Pixel pitch: 0.0765 mm
• Power consumption (maximum): 5.41 W
• Anti-glare vs Anti-reflective: Anti-reflective
• Touch options: Yes

4-cell “smart” lithium-ion (52 WHr)

7.60 VDC

0.22 kg (0.48 lb)

4.30 mm (0.17 in.)

257.60 mm (10.14 in.)

98.60 mm (3.88 in.)

0°C to 35°C (32°F to 95°F)

–40°C to 65°C (–40°F to 149°F)

4 hours (when the computer is off)

ML1220

One

Fixed focus lens

Top-mount front camera

CMOS sensor technology

0.9 megapixels (HD)

1280 x 720 (HD) at 30 fps

78 degrees

Realtek ALC3271-CG with Waves MaxxAudio Pro

Supported

High-definition audio

7.1 channel output, universal audio jack supports microphone-in, stereo headphones, and headset combo

Two

Supported

Supported

2 W

2.5 W

Not supported

Digital-array microphones

One microSD-card slot

• microSecure Digital (mSD)
• microSecure Digital High Capacity (mSDHC)
• microSD Extended Capacity (mSDXC)

Two Thunderbolt 3 (USB Type-C) ports with Power Delivery

One headset (headphone and microphone combo) port

One USB 3.1 Gen 2 (USB Type-C) port with Power Delivery/DisplayPort

MicroSD card reader

Not supported

DC-IN through USB Type-C

Wedge-shaped lock

One M.2 slot for 2280/2230 Solid-State Drive (SSD)

• Model number: Killer 1435-S
• Transfer rate: Up to 867 Mbps
• Frequency bands supported: Dual band 2.4 GHz/5 GHz
• Wireless standards: WiFi 802.11a/b/g/n/ac
• Encryption
  • 64-bit/128-bit WEP
  • AES-CCMP
  • TKIP
• Bluetooth: Bluetooth 4.2

• Model number: Intel 9260
• Transfer rate: Up to 1733 Mbps
• Frequency bands supported: Dual band 2.4 GHz/5 GHz
• Wireless standards
  • WiFi 802.11a/b/g
  • Wi-Fi 4 (WiFi 802.11n)
  • Wi-Fi 5 (WiFi 802.11ac)
• Encryption
  • 64-bit/128-bit WEP
  • AES-CCMP
  • TKIP
• Bluetooth: Bluetooth 5

Backlit keyboard

QWERTY

• United States and Canada: 82 keys
• United Kingdom: 83 keys
• Japan: 86 keys

X=19.05 mm key pitch

Y=18.05 mm key pitch

305

305

105 mm (4.13 in.)

60 mm (2.36 in.)

Touch

500 dpi

5.5 mm x 4.5 mm

108 x 88 pixels

45 W USB (Type-C)

Not supported

100 VAC-240 VAC

50 Hz-60 Hz

1.30 A

• 20 VDC/2.25 A
• 15 VDC/3 A
• 9 VDC/3 A
• 5 VDC/3 A

20 VDC/15 VDC/9 VDC/5 VDC

0°C to 40°C (32°F to 104°F)

–40°C to 70°C (–40°F to 158°F)
